Dynamic Facial Recognition Access Control System

Introduction

This product is a state-of-the-art face recognition access control system that offers multi-functionality. It features a new AI processor design and an RTOS intelligent operating system, providing powerful functions in a stable and reliable manner. With various access modes including standalone mode, it can be applied in a wide range of settings such as offices, homes, villas, banks, and prisons.

Technical parameters:

Recognition distance: pure dynamic face recognition: 0.5-3 meters Open living body 0.5-1.5 meters

Intelligent function: infrared living body identification

Integration：Can be Wired to Output Card Reader externally connected to the access control controller system

System：RTOS Intelligent Operating System

Working voltage: DC12V-10%

Power supply requirements: DC12V 3-5A

LCD display: 5-inch LCD screen, capacitive touch screen 272 * 480

Working temperature: – 15 ℃~+45 ℃ (storage temperature: – 10 ℃~+65 ℃)

Working relative humidity: 20%~90% (storage humidity: 20%~90 ± 2%)

Waterproof grade: IP65

User capacity: 2000

User records: 100000

Attendance records: download from USB flash disk

Keyboard: touch screen virtual keys

Authentication method: face/card/password, face + password, face + card/Tuya App Remote Control/Tuya App Temporary Password

Card frequency: 125Khz ID EM card

2 Cameras：2M Pixel HD color camera

2 Infrared Cameras：Infrared anti-counterfeiting camera

Specification
